Micro
High precision cutting tool for fine parts and micro components.
Overview
The Micro machine is specially designed to cut at high precision with extreme tolerances. The Micro cuts fine details with very little material loss.
Technical specifications
Technical data
| Construction | Gantry |
|---|---|
| Frame | Welded |
| Cutting Table/Tank | Stainless Steel |
| Cutting Table Frame | Mineral Casting Bearlit® |
| Motion System | Ballscrew / Renishaw RESOLUTE RELA® invar scale |
| Control Unit | Panel One HMI |
| CNC control system | Fanuc |
| Process | FAWJ compatible |
| Pressure Technology | 4000 bar |
| Machine size | 1×1 m (3'3"x3'3") |
Performence
| Maximum piece thickness | 100 mm (3.9") |
|---|---|
| Positioning Accuracy | ± 0.01 mm/300 mm (0.0004"/11.8") (20°C ± 2°) |
| Repetition Accuracy | ± 0.008 mm (± 0.0003") (20°C ± 2°) |
Product features
WJS Micro Cutting Head
A state of the art precision tool producing one of the most precise abrasive water jets in the world.
Mineral Casting Bearlit Table Frame
For excellent stiffness, accuracy and absorption.
Renishaw Invar Scale
With extremely low expansion coefficient and high resolution.
Palletized Cutting Table
Offer outstanding opportunities for fixturing.
Rubber Suspended Stainless Steel Catcher
To avoid vibration and thermal influence.
Software Controlled Abrasive Feeding
To sense feed rate, blockage and critical level in abrasive buffer.
